Advantages
- Complete steel construction
- Vacuum gauge to detect filter clogging
- Compact and mobile
- Easy filter replacement
- PPL filter for chips separation
- Floating device to stop the suction when container is full
- Discharge hose for liquids
- Compressed air supply through a single Venturi suction unit
- Easy to handle
- Powerful suction thanks to a multi-nozzle venturi unit
- Exceptional consuption perfomance rate
Technical data
- Air supply: 1458 nlt/min (87 nm3/h)
- Air supply pressure: 6 bar
- Ø Air supply hose: 12 mm
- Max waterlift: 3700 mmH2O
- Max air flow: 300 m3/h
- Suction inlet: 80 mm
- Capacity: 80 lt.
- Noise level (EN ISO 3744): 68 dB(A)
- Dimensions l/w/h: 53x59x100 cm
- Weight: 33 kg
- Dry filter Type: Bag
- Surface – Diameter: 8.000 cm2/420 mm
- Material – Efficiency: Nylon+Polyester/L (IEC 60335-2-69)
- Air load on filter: 375 m3/m2/h
- Wet filter Type: Bag
- Surface – Diameter: 8.000 cm2/420 mm
- Material – Efficiency: Polypropilene/300 micron (IEC 60335-2-69)
Optionals
- Stainless steel AISI 304 collection tank
