Advantages
- Tangential suction inlet with integrated separation cyclone
- PPL filter for chips separation
- Floating device to stop the suction when container is full
- Reduced downtime of machine tools
- Submerged pump for the discharge of the sucked liquid
- Grid for chips vacuuming
- Simultaneous operation of liquids vacuuming and discharge
- Possibility of recycling oils and emulsions
- Reduction of disposal costs due to exhausted oils
- Reduction of machineries cleaning times
Technical data
- Voltage: 230V, 50Hz
- Power: 3,45 kW
- Current draw: 15 A
- Max waterlift: 2500 mmH2O
- Max air flow: 540 m3/h
- Suction inlet: 50 mm
- Liquids capacity: 60 lt.
- Solids capacity: 40 lt.
- Media/Filtration: Polypropilene/300µm
- Noise level (EN ISO 3744): 76 dB(A)
- Dimensions: 67x66x125 cm
- Weight: 70 kg
- Filter Type: 3D SuperWeb
- Diameter: 500 mm
- Media, filtration: Polypropilen 20 micron
- Oil&Water proof cartridge: Optional
- Discharge system: Immersion pump
- Discharge speed: 160 lt/min
- Floating device: electrical
Optionals
- Oil&Water repellent cartridge
- Stainless steel sieve grid
- Stainless steel AISI 304 collection tank
- Stainless steel AISI 304 collection tank and filter chamber
- ABS accessory basket
