Advantages
- Largest surface filter in its category
- Integrated filter cleaning system
- Complete steel construction
- Extractable collection container with optional use of disposable bags
- Three powerful by pass motors with independent cooling
- Compact and mobile
- Easy filter replacement
Technical data
- Voltage: 230V, 50Hz
- Power: 3,45 kW
- Current draw: 15 A
- Max waterlift: 2500 mmH2O
- Max air flow: 540 m3/h
- Suction inlet: 80 mm
- Capacity: 100 lt.
- Noise level (EN ISO 3744): 76 dB(A)
- Dimensions l/w/h: 77x66x150 cm
- Weight: 85 kg
- Filter Type: Star
- Surface – Diameter: 30.000 cm2/500 mm
- Material – Efficiency: Poliester/ANT M (IEC 60335-2-69)
- Air load on filter: 180 m3/m2/h
- Cleaning system: Manual
- Discharge system: Roll-out container
Optionals
- Additional Absolute filter
- Class M antistatic filter
- Class M filter with PTFE coating
- Nomex 200°Celsius heat resistant filter
- Stainless steel AISI 304 collection tank
- Stainless steel AISI 304 collection tank and filter chamber
- Cyclon for filter protection
- Earth grounding
- Earth grounding/ANT filter/Chain
- Accessory basket and double bend holder
- Ring for disposable bag use
- Pressure differential kit for disp bags
- Internal polishing for tank
- Internal polishing for filtering chamber
