Advantages
- Largest surface filter in its category
- Integrated filter cleaning system
- Complete steel construction
- Extractable collection container with optional use of disposable bags
- Two powerful by pass motors with independent cooling
- Low noise level
- Compact and mobile
- Easy filter replacement
- Accessory kit as standard
Technical data
- Voltage: 230V, 50Hz
- Power: 2,3 kW
- Curren draw: 10A
- Max waterlift: 2500 mmH2O
- Max air flow: 360 m3/h
- Suction inlet: 50 mm
- Capacity: 20 lt.
- Noise level (EN ISO 3744): 76 dB(A)
- Dimensions l/w/h: 59x48x110 cm
- Weight: 35 kg
- Filter Type: Cartridge
- Surface – Diameter: 30.000 cm2/360 mm
- Material – Efficiency: Poliester/M PTFE (IEC 60335-2-69)
- Air load on filter: 120 m3/m2/h
- Cleaning system: Dustop
- Discharge system: Roll-out container
Optionals
- Cartridge HEPA H14 absolute filter
- Class M antistatic filter
- Stainless steel container
- Stainless steel container and chamber
- Stainless steel container and chamber and chasis
- Earth grounding
- Earth grounding/antistatic filter/chain
- Accessory basket
- 3mt hose holder
- Remote control 1150 VA
- Sliding damper for Dustop
- Spare disposable bag (5 pieces)
