Model description
- Overheat thermostat
- High quality fuel pump
- Post ventilation
- Transparent external suction filter
- Possible connection to a fuel pre-heate
- High air displacement
- Electric control panel humidity and dust proof(Ingress Protection IP44)
- Possible connection to an optional room thermostat
- Three oil filters: oil pump filter, suction filter and inlet filter
- Thermally protected motor
- Electronic flame control with photocell
- Stainless steel combustion chamber
- Oil tank with level indicator
- Trolley included
- Snorkel
- Easy maintenance with external pump
- Strong and long lasting construction
- Diagnostic LED
How to choose the right device >link<
Technical data
- Power: 111 kW
- Air displacement: 3300 m3/h
- Power supply: 230 V, 50 Hz
- Protection: IP 41
- Fuel consumption: 10,6 lit/h
- Rated current: 4,6 A
- Electric power: 1,06 kW
- Tank capacity: 105 liters
- Thermostat control: analog or digital
- Fuel autonomy: 10 hours
- Product size l/w/h: 1600x700x940 mm
- Packaging dimensions l/w/h: 1600x750x1180 mm
- Weight net/gross: 84/105 kg
