Advantages
- Side channel blower motor , powerful and silent, totally maintenance free, suitable for continuous duty
- Integrated filter cleaning system
- Complete steel construction
- Pressure relief valve for motor protection
- Low noise level
- Easy filter replacement
- Reduced downtime of machine tools
- Possibility of integration on other vacuum cleaners
- Modularity is guaranteed to fulfil the client’s needs
- Full customization for specific needs
- Compliance with EN IEC 62784:2018 for Zone 22
Technical data
- User zone: Ord. location, ATEX 22
- Marking: II 3D Ex h tc IIIC T80°C (int)/T165°C(ext) Dc
- Ex Category: 3D (20 int/22 ext)
- Voltage: 400V, 50Hz
- Power: 2,2 kW
- Current draw: 4,6 A
- Electrical protection: IP 65
- Pressure relief valve: Included
- Max waterlift: 3000 mmH2O
- Continuous waterlift: 2200 mmH2O
- Max air flow: 270 m3/h
- Suction inlet: 50 mm
- Capacity: 25 lt.
- Noise level (EN ISO 3744): 69 dB(A)
- Dimensions l/w/h: 54x55x103 cm
- Weight: 45 kg
- Primary filter: Star
- Surface/Diameter: 8.000 cm2/360 mm
- Material/Efficiency: Polyester/ANT M (IEC 60335-2-69)
- Filter cleaning: Manual
- Class H-HEPA filter: Included
- Filter grade: H14 with 99/995% efficiency on MPPS method
Optionals
- Stainless steel collection tank
- Stainless steel AISI 304 construction
- Chassis with casters and push handle
