Advantages
- Side channel blower motor , powerful and silent, totally maintenance free, suitable for continuous duty
- Integrated filter cleaning system
- Tangential suction inlet with integrated separation cyclone
- Pressure relief valve for motor protection
- ATEX certified for Zone 20 inside the chamber and for Zone 21 outside the chamber
- Large surface antistatic filter
- Conceived for fine and hazardous dust suction
- Additional HEPA filter (99,995% on 0,18 micron) included
- Stainless steel AISI304 collection tank
ATEX Vacuum Cleaners: the complete guide >link<
Technical data
- Atex zones: 20/21
- Marking: Ex II 1/2D Ex h lllC T160°C Da/Db
- Voltage: 400V, 50 Hz
- Power: 18,5 kW
- Electrical protection: IP 65
- Max waterlift: 1800 mmH2O
- Max air flow: 2050 m3/h
- Suction inlet: 120 mm
- Noise level (EN ISO 3744): 78 dB(A)
- Filter Type: Star
- Surface – Diameter: 120.000 cm2/780 mm
- Material – Efficiency: Polyester/ANT M (IEC 60335-2-69) + HEPA
- Cleaning system: Automatic AUT
- Capacity: 220 lt. Stainless Steel
- Dimensions l/w/h: 95x180x220 cm
- Weight: 810 kg
Optionals
- Stainless steel AISI 304 collection tank and filter chamber
- Automatic reverse pulse jet cleaning system, 4 cartridges
